6063 is a heat-treatable alloy containing magnesium and silicon, known for its excellent extrusion properties. It can be rapidly extruded into thin-walled aluminum tubes with a smooth, high-quality surface.
Due to its finer grain structure, it provides outstanding anodizing results, making it ideal for architectural and decorative applications, often referred to as "architectural aluminum."
It is also widely used in cylinders, aluminum bus bars, transportation, and furniture decoration.
|
6063 aluminum tubing Specification:ASTM B221, EN 755-9,ASTM B241/B241M,EN 754 |
6063 aluminum pipe Specification:ASTM B241, EN 754,ASTM B429 |
Physical properties of 6063 aluminum tube
| T52 | T6 | |
| Density | 0.098 lb/in3 | 0.098 lb/in3 |
| Ultimate Tensile Strength | 27 ksi | 35 ksi |
| Yield Tensile Strength | 21 ksi | 31 ksi |
| Fatigue Strength | 9.7 ksi | 10 ksi |
| Shear Strength | 15 ksi | 22 ksi |
| Shear Modulus | 3,700 ksi | 3,770 ksi |
| Hardness Rockwell | Brinell | B17 | 60 | B27 | 65 |
| Elongation at Break Percentage | 12% | 22% |
| Modulus of Elasticity | 10,000 ksi | 10,000 ksi |
| Poisson's Ratio | 0.33 | 0.33 |
| Machinability Percentage | N/A | 50% |
| Melting Point | 1,140-1,210 °F | 1,140-1,210 °F |
| Specific Heat | 2.15 x 10^-1 BTU/lb-°F | 2.15 x 10^-1 BTU/lb-°F |
| Thermal Conductivity | 1,450 BTU-in/hr-ft^2-°F | 1,390 BTU-in/hr-ft^2-°F |
| Electrical Conductivity | 53% IACS | 53% IACS |
Product categories of 6063 aluminum tube
6063 aluminum round tube
-
6063 aluminum round tube- OD: 5-450mm
- Temper: T5, T52, T6, T832
- 6063 aluminum tubing is commonly used for structural applications, such as frames and railings. Precision in outer diameter and wall thickness is crucial to ensure stability within structural components.
| Description | OD | WA | Manufacture Method |
| 0.500"(OD) x 0.050"(WA) 6063-T52 aluminum tube | 0.500" | 0.050" | Extruded |
| 0.500"(OD) x 0.058"(WA) 6063-T832 aluminum tube | 0.500" | 0.058" | Drawn |
| 0.625"(OD) x 0.049"(WA) 6063-T52 aluminum tube | 0.625" | 0.049" | Extruded |
| 0.750"(OD) x 0.049"(WA) 6063-T52 aluminum tube | 0.750" | 0.049" | Extruded |
| 0.750"(OD) x 0.058"(WA) 6063-T832 aluminum tube | 0.750" | 0.058" | Drawn |
| 0.750"(OD) x 0.065"(WA) 6063-T52 aluminum tube | 0.750" | 0.065" | Extruded |
| 0.750"(OD) x 0.125"(WA) 6063-T52 aluminum tube | 0.750" | 0.125" | Extruded |
| 0.875"(OD) x 0.058"(WA) 6063-T832 aluminum tube | 0.875" | 0.058" | Drawn |
| 0.875"(OD) x 0.062"(WA) 6063-T52 aluminum tube | 0.875" | 0.062" | Extruded |
| 1.000"(OD) x 0.062"(WA) 6063-T52 aluminum tube | 1.000" | 0.062" | Extruded |
| 1.000"(OD) x 0.125"(WA) 6063-T52 aluminum tube | 1.000" | 0.125" | Extruded |
| 1.125"(OD) x 0.042"(WA) 6063-T832 aluminum tube | 1.125" | 0.042" | Drawn |
| 1.250"(OD) x 0.062"(WA) 6063-T52 aluminum tube | 1.250" | 0.062" | Extruded |
| 1.250"(OD) x 0.090"(WA) 6063-T52 aluminum tube | 1.250" | 0.090" | Extruded |
| 1.250"(OD) x 0.125"(WA) 6063-T52 aluminum tube | 1.250" | 0.125" | Extruded |
| 1.375"(OD) x 0.062"(WA) 6063-T52 aluminum tube | 1.375" | 0.062" | Extruded |
| 1.500"(OD) x 0.062"(WA) 6063-T52 aluminum tube | 1.500" | 0.062" | Extruded |
| 1.500"(OD) x 0.065"(WA) 6063-T52 aluminum tube | 1.500" | 0.065" | Extruded |
| 1.500"(OD) x 0.125"(WA) 6063-T52 aluminum tube | 1.500" | 0.125" | Extruded |
| 1.500"(OD) x 0.188"(WA) 6063-T52 aluminum tube | 1.500" | 0.188" | Extruded |
| 1.750"(OD) x 0.065"(WA) 6063-T52 aluminum tube | 1.750" | 0.065" | Extruded |
| 2.000"(OD) x 0.050"(WA) 6063-T52 aluminum tube | 2.000" | 0.050" | Extruded |
| 2.000"(OD) x 0.065"(WA) 6063-T52 aluminum tube | 2.000" | 0.065" | Extruded |
| 2.000"(OD) x 0.125"(WA) 6063-T52 aluminum tube | 2.000" | 0.125" | Extruded |
| 3.000"(OD) x 0.050"(WA) 6063-T52 aluminum tube | 3.000" | 0.050" | Extruded |
| 3.000"(OD) x 0.083"(WA) 6063-T52 aluminum tube | 3.000" | 0.083" | Extruded |
| 3.000"(OD) x 0.125"(WA) 6063-T52 aluminum tube | 3.000" | 0.125" | Extruded |
| 3.000"(OD) x 0.065"(WA) 6063-T6 aluminum tube | 3.000" | 0.065" | Extruded |
| 4.000"(OD) x 0.125"(WA) 6063-T52 aluminum tube | 4.000" | 0.125" | Extruded |
| 5.000"(OD) x 0.125"(WA) 6063-T52 aluminum tube | 5.000" | 0.125" | Extruded |
| 6.000"(OD) x 0.125"(WA) 6063-T52 aluminum tube | 6.000" | 0.125" | Extruded |
| 8.000"(OD) x 0.125"(WA) 6063-T52 aluminum tube | 8.000" | 0.125" | Extruded |
| 10.000"(OD) x 0.094"(WA) 6063-T6 aluminum tube | 10.000" | 0.094" | Extruded |
6063 aluminum pipe
-
6063 aluminum pipe- 6063 aluminum pipe is commonly used in fluid transport systems, such as water pipes and gas/liquid pipelines. Precision in inner diameter is critical to ensure smooth fluid flow.
Hot selling size of 6063 aluminum pipe
| Description | OD | WA | Manufacture Method |
| 0.125" Schedule 40 Pipe 6063-T52 | 0.405" | 0.068" | Extruded Seamless |
| 0.125" Schedule 80 Pipe 6063-T52 | 0.405" | 0.095" | Extruded Seamless |
| 0.250" Schedule 40 Pipe 6063-T52 | 0.540" | 0.088" | Extruded Seamless |
| 0.250" Schedule 80 Pipe 6063-T52 | 0.540" | 0.119" | Extruded Seamless |
| 0.375" Schedule 40 Pipe 6063-T52 | 0.675" | 0.091" | Extruded Seamless |
| 0.500" Schedule 40 Pipe 6063-T52 | 0.840" | 0.109" | Extruded Seamless |
| 0.500" Schedule 80 Pipe 6063-T52 | 0.840" | 0.147" | Extruded Seamless |
| 0.750" Schedule 40 Pipe 6063-T52 | 1.050" | 0.113" | Extruded Seamless |
| 1.000" Schedule 40 Pipe 6063-T52 | 1.315" | 0.133" | Extruded Seamless |
| 1.000" Schedule 80 Pipe 6063-T52 | 1.315" | 0.179" | Extruded Seamless |
| 1.250" Schedule 40 Pipe 6063-T52 | 1.660" | 0.140" | Extruded Seamless |
| 1.250" Schedule 80 Pipe 6063-T52 | 1.660" | 0.191" | Extruded Seamless |
| 1.500" Schedule 10 Pipe 6063-T52 | 1.900" | 0.109" | Extruded Seamless |
| 1.500" Schedule 40 Pipe 6063-T52 | 1.900" | 0.145" | Extruded Seamless |
| 1.500" Schedule 80 Pipe 6063-T52 | 1.900" | 0.200" | Extruded Seamless |
| 2.000" Schedule 40 Pipe 6063-T52 | 2.375" | 0.154" | Extruded Seamless |
| 2.000" Schedule 80 Pipe 6063-T52 | 2.375" | 0.218" | Extruded Seamless |
| 2.500" Schedule 40 Pipe 6063-T52 | 2.875" | 0.203" | Extruded Seamless |
| 2.500" Schedule 80 Pipe 6063-T52 | 2.875" | 0.276" | Extruded Seamless |
| 3.000" Schedule 10 Pipe 6063-T52 | 3.500" | 0.120" | Extruded Seamless |
| 3.000" Schedule 80 Pipe 6063-T52 | 3.500" | 0.300" | Extruded Seamless |
| 3.500" Schedule 10 Pipe 6063-T52 | 4.000" | 0.120" | Extruded Seamless |
| 3.500" Schedule 40 Pipe 6063-T52 | 4.000" | 0.226" | Extruded Seamless |
| 3.500" Schedule 80 Pipe 6063-T52 | 4.000" | 0.318" | Extruded Seamless |
| 4.000" Schedule 10 Pipe 6063-T52 | 4.500" | 0.120" | Extruded Seamless |
| 4.000" Schedule 40 Pipe 6063-T52 | 4.500" | 0.237" | Extruded Seamless |
| 4.000" Schedule 80 Pipe 6063-T52 | 4.500" | 0.337" | Extruded Seamless |
| 5.000" Schedule 40 Pipe 6063-T52 | 5.563" | 0.258" | Extruded Seamless |
| 5.000" Schedule 80 Pipe 6063-T52 | 5.563" | 0.375" | Extruded Seamless |
| 6.000" Schedule 40 Pipe 6063-T52 | 6.625" | 0.280" | Extruded Seamless |
| 6.000" Schedule 80 Pipe 6063-T52 | 6.625" | 0.432" | Extruded Seamless |
| 8.000" Schedule 40 Pipe 6063-T52 | 8.625" | 0.322" | Extruded Seamless |
| 8.000" Schedule 80 Pipe 6063-T52 | 8.625" | 0.500" | Extruded Seamless |
| 10.000" Schedule 40 Pipe 6063-T52 | 10.750" | 0.365" | Extruded Seamless |
| 10.000" Schedule 80 Pipe 6063-T52 | 10.750" | 0.594" | Extruded Seamless |
| 12.000" Schedule 40 Pipe 6063-T52 | 12.750" | 0.375" | Extruded Seamless |
| 12.000" Schedule 80 Pipe 6063-T52 | 12.750" | 0.688" | Extruded Seamless |
6063 aluminum square tube
-
6063 aluminum square tube- The 6063 aluminum square tube offers greater stability in multi-directional structures, making it ideal for applications requiring high structural stability and multi-directional contact, such as architectural decorations, frames, and railings.
Hot selling size of 6063 aluminum square tube
| Description | Size | Wall | Manufacture method |
| 0.75"x 0.062"6063 T52 Aluminum Square Tube | 3/4 | 0.062 | Extruded structural |
| 0.75"x 0.125"6063 T52 Aluminum Square Tube | 3/4 | 0.125 | Extruded structural |
| 1"x 0.125"6063 T52 Aluminum Square Tube | 1 | 0.125 | Extruded structural |
| 1"x 0.062"6063 T52 Aluminum Square Tube | 1 | 0.062 | Extruded structural |
| 1.25"x 0.125"6063 T52 Aluminum Square Tube | 1 1/4 | 0.125 | Extruded structural |
| 1.5"x 0.125"6063 T52 Aluminum Square Tube | 1 1/2 | 0.125 | Extruded structural |
| 1.75"x 0.125"6063 T52 Aluminum Square Tube | 1 3/4 | 0.125 | Extruded structural |
| 2"x 0.125"6063 T52 Aluminum Square Tube | 2 | 0.125 | Extruded structural |
| 2"x 0.187"6063 T52 Aluminum Square Tube | 2 | 0.187 | Extruded structural |
| 2"x 0.25"6063 T52 Aluminum Square Tube | 2 | 0.25 | Extruded structural |
| 2.5"x 0.125"6063 T52 Aluminum Square Tube | 2 1/2 | 0.125 | Extruded structural |
| 2.5"x 0.187"6063 T52 Aluminum Square Tube | 2 1/2 | 0.187 | Extruded structural |
| 3"x 0.125"6063 T52 Aluminum Square Tube | 3 | 0.125 | Extruded structural |
| 3"x 0.187"6063 T52 Aluminum Square Tube | 3 | 0.187 | Extruded structural |
| 3"x 0.25"6063 T52 Aluminum Square Tube | 3 | 0.25 | Extruded structural |
| 4"x 0.125"6063 T52 Aluminum Square Tube | 4 | 0.125 | Extruded structural |
| 4"x 0.25"6063 T52 Aluminum Square Tube | 4 | 0.25 | Extruded structural |
6063 aluminum rectangle tube
-
6063 aluminum rectangle tube- The rectangular cross-section of the 6063 aluminum rectangle tube allows for better space utilization, making it advantageous in confined installation environments. It is commonly used in mechanical components, industrial structures, and architectural decorations.
Hot selling size of 6063 aluminum rectangle tube
| Description | SIZE(B) | SIZE(A) | Wall | Manufacture Method |
| 0.5"x 1"x 0.125"6063 T52 Aluminum Rectangular tube | 1/2 | 1 | 0.125 | extruded structural |
| 0.75"x 1.5"x 0.125"6063 T52 Aluminum Rectangular tube | 3/4 | 1 1/2 | 0.125 | extruded structural |
| 1"x 1.5"x 0.062"6063 T52 Aluminum Rectangular tube | 1 | 1 1/2 | 0.062 | extruded structural |
| 1"x 1.5"x 0.125"6063 T52 Aluminum Rectangular tube | 1 | 1 1/2 | 0.125 | extruded structural |
| 1"x 2"x 0.062"6063 T52 Aluminum Rectangular tube | 1 | 2 | 0.062 | extruded structural |
| 1"x 2"x 0.125"6063 T52 Aluminum Rectangular tube | 1 | 2 | 0.125 | extruded structural |
| 1"x 3"x 0.125"6063 T52 Aluminum Rectangular tube | 1 | 3 | 0.125 | extruded structural |
| 1"x 4"x 0.125"6063 T52 Aluminum Rectangular tube | 1 | 4 | 0.125 | extruded structural |
| 1.25"x 2.5"x 0.125"6063 T52 Aluminum Rectangular tube | 1 1/4 | 2 1/2 | 0.125 | extruded structural |
| 1.5"x 2"x 0.125"6063 T52 Aluminum Rectangular tube | 1 1/2 | 2 | 0.125 | extruded structural |
| 1.5"x 2.5"x 0.125"6063 T52 Aluminum Rectangular tube | 1 1/2 | 2 1/2 | 0.125 | extruded structural |
| 1.5"x 3"x 0.125"6063 T52 Aluminum Rectangular tube | 1 1/2 | 3 | 0.125 | extruded structural |
| 1.5"x 3"x 0.188"6063 T52 Aluminum Rectangular tube | 1 1/2 | 3 | 0.188 | extruded structural |
| 1.5"x 6"x 0.125"6063 T52 Aluminum Rectangular tube | 1 1/2 | 6 | 0.125 | extruded structural |
| 1.75"x 3"x 0.125"6063 T52 Aluminum Rectangular tube | 1 3/4 | 3 | 0.125 | extruded structural |
| 1.75"x 3.5"x 0.125"6063 T52 Aluminum Rectangular tube | 1 3/4 | 3 1/2 | 0.125 | extruded structural |
| 1.75"x 4"x 0.125"6063 T52 Aluminum Rectangular tube | 1 3/4 | 4 | 0.125 | extruded structural |
| 1.75"x 5"x 0.125"6063 T52 Aluminum Rectangular tube | 1 3/4 | 5 | 0.125 | extruded structural |
| 2"x 3"x 0.125"6063 T52 Aluminum Rectangular tube | 2 | 3 | 0.125 | extruded structural |
| 2"x 4"x 0.125"6063 T52 Aluminum Rectangular tube | 2 | 4 | 0.125 | extruded structural |
| 2"x 4"x 0.188"6063 T52 Aluminum Rectangular tube | 2 | 4 | 0.188 | extruded structural |
| 2"x 4"x 0.25"6063 T52 Aluminum Rectangular tube | 2 | 4 | 0.25 | extruded structural |
| 2"x 5"x 0.125"6063 T52 Aluminum Rectangular tube | 2 | 5 | 0.125 | extruded structural |
| 2"x 6"x 0.125"6063 T52 Aluminum Rectangular tube | 2 | 6 | 0.125 | extruded structural |
| 2"x 6"x 0.25"6063 T52 Aluminum Rectangular tube | 2 | 6 | 0.25 | extruded structural |
| 3"x 4"x 0.125"6063 T52 Aluminum Rectangular tube | 3 | 4 | 0.125 | extruded structural |
| 3"x 5"x 0.125"6063 T52 Aluminum Rectangular tube | 3 | 5 | 0.125 | extruded structural |
| 3"x 6"x 0.188"6063 T52 Aluminum Rectangular tube | 3 | 6 | 0.188 | extruded structural |
Mastar 6063 aluminum tubing: featured products
-
6063 aluminum flat oval tubing
-
6063 rectangular tubing with rounded corners
-
6063 thin wall aluminum tube
-
6063 seamless aluminum tube
-
6063 telescopic aluminum tube
-
6063 tapered aluminum pipe
-
6063 anodized aluminum tubing
-
Bending 6063 aluminum tubing
-
Aluminum 6063 t5 cylinder tube
What are the characteristics of 6063 aluminum tubing?
6063 is one of the most suitable materials for extrusion in the 6000 series, widely used in architectural decoration, earning it the nickname "architectural aluminum." Its strength is about half that of 6061, but it has much better surface smoothness and excellent anodizing performance. Key characteristics include:
- Medium strength
- Excellent surface quality
- Good corrosion resistance
- Good formability
- Superior anodizing performance
- Excellent finishing capabilities
- Good weldability
Ideal applications for 6063 aluminum tubing
6063 aluminum tubing is widely used across multiple industries, including construction, transportation, industrial manufacturing, power, and sports, due to its excellent extrusion performance and smooth surface finish. Specific applications include:
-
Construction Industry- Door and window frames
- Railings and handrails
- Structural framework support
-
Power Industry- Cable conduits
- Aluminum buspipe
- Cable bridge supports for power towers
-
Transportation Industry- Cylinder tubes
- Bus railings and handrails
- Bicycle frames
-
Industrial Manufacturing- Radiators and cooling devices
- Equipment frameworks
- Hydraulic systems
-
Furniture and Decoration- Furniture frames
- Display cabinets and shelving
- Lamp stands
Mastar Metal - premium aluminum tube supplier
- Product Quality: We strictly adhere to multiple inspection processes to ensure our aluminum tubes meet AMS, EN, and NADCAP standards. Quality is monitored throughout to ensure each tube is reliable.
- Delivery Time: With tens of thousands of tons in stock and standard sizes readily available, we ensure quick shipping. Our advanced equipment and professional team minimize lead times, offering convenient logistics and timely delivery.
- Price Advantage: We support both retail and bulk purchases for metal distributors, offering discounts and rebate policies for large orders. Our pricing is transparent and competitive, ensuring value for money with the same quality products.
- Customer Service: We provide comprehensive after-sales support to address any concerns. Our experienced technical team offers professional advice and guidance, with a well-established customer service system to ensure a high-quality service experience.
Why is 6063 aluminum tubing suitable for use as bus pipe?
6063 aluminum buspipe have excellent electrical conductivity, mechanical properties, and corrosion resistance, making them ideal for power transmission and distribution systems. They ensure efficient current transmission and require no additional maintenance over long-term use.
What are the differences between 6061 and 6063 aluminum tubes?
6061 and 6063 are two of the most widely used aluminum tubes. Their chemical composition and mechanical properties are very similar, but the magnesium content differs, leading to variations in strength:
| Features | 6061 | 6063 |
| Tensile strength | Medium to high strength | Medium strength |
| Mechanical properties | Excellent | Good |
| Corrosion resistance | Good | Excellent |
| Electrical properties | Low | High |
| Thermal conductivity | Medium | High |
| Processing properties | Good | Good |
| Surface finish | General | Excellent |
| Application range | Aerospace, automotive, construction | Architectural decoration, door and window frames, furniture |
- 6061 aluminum tubing is one of the most commonly used aluminum alloys due to its versatility and excellent strength-to-weight ratio. It has a low melting point, high strength, and good weldability, commonly available in T4 and T6 tempers. However, its corrosion resistance and surface finish are not as good as those of 6063 aluminum tubes.
- 6063 aluminum tubing is known for its excellent surface finish and superior corrosion resistance. It can also be extruded at high speeds to produce thin-walled tubes, with exceptional results after anodizing. However, its strength is about half that of 6061, making it more suitable for architectural and decorative applications. Additionally, 6063 is more cost-effective than 6061, making it the best choice for non-structural appearance parts.
Mastar Metal also offers a wide range of other high-performance aluminum tubes, such as 2024 aluminum tubes, 7075 aluminum tubes, and 6082 aluminum tubes. If you need more information, feel free to contact us.Quick Quote
What support can we offer metal distributors?
Mastar Metal maintains a substantial inventory, including standard sizes of 6061 and 6063 aluminum tubes. We can provide you with a reliable supply chain. All our products meet international standards, ensuring consistent quality and performance. For distributors making bulk purchases, we offer rebate or discount policies, helping you obtain reliable products at a lower cost and enhancing your market competitiveness.
How can I order 6063 aluminum tubes as a retailer?
Mastar Metal supports pooled orders of various sizes and specifications. As long as you can handle customs clearance and pick-up, simply specify the outer diameter, wall thickness, alloy, and temper of the aluminum tubes you need, then select your preferred packaging, payment method, and delivery date. We handle the rest. Additionally, we offer excellent after-sales support to ensure a smooth procurement process for you.
