Aluminum Awning Extrusions

Updated :

Thanks to their lightweight, corrosion-resistant, and high-strength characteristics, aluminum profiles are the ideal choice for awning construction. MASTAR offers a variety of high-quality aluminum alloy profiles for awnings. For more information and pricing, please contact us.

Specifications for aluminum awning profiles

Alloy: 6063 6061

Temper: T5 T6

Price: Quote based on drawings

Specifications: ASTM B429, ASTM B221, ASTM B308

Surface: Anodizing, powder coating, polishing, sandblasting, and brushing

Types of aluminum profiles for awnings

Aluminum profiles for awning tracks

  • 45 Degree aluminum Awning rail
    45 Degree aluminum Awning rail
  • 90 Degree aluminum Awning rail
    90 Degree aluminum Awning rail
  • 180 Degree aluminum Awning rail
    180 Degree aluminum Awning rail

Aluminum profiles for awning mounts

  • Aluminum Awning Tube - Rope Channel
    Aluminum Awning Tube - Rope Channel
  • Aluminum Awning Tube – Rope Channel with Flange
    Aluminum Awning Tube – Rope Channel with Flange
  • Aluminum Awning Staple Tube With Double Flange
    Aluminum Awning Staple Tube With Double Flange
  • Aluminum Awning Staple Tube
    Aluminum Awning Staple Tube
  • Aluminum Awning Staple Tube with Flange
    Aluminum Awning Staple Tube with Flange
  • OP-Side Staple Round Corner
    OP-Side Staple Round Corner

Aluminum Awning Hardware

  • Z Bracket
    Z Bracket
  • U Joining Bracket
    U Joining Bracket
  • L Bracket
    L Bracket
  • Flat Link Plate
    Flat Link Plate
  • Hinge Brackets
    Hinge Brackets
  • Head Rod Clamp
    Head Rod Clamp

Custom Aluminum Awning Shapes

  • Roller Tube
    Roller Tube
  • Awning Frame Pan
    Awning Frame Pan
  • Awning Frame Beam
    Awning Frame Beam
  • Constructed Awning Frame (Pan & Beam)
    Constructed Awning Frame (Pan & Beam)
  • Constructed Awning Frame (Pan & Beam)
    Constructed Awning Frame (Pan & Beam)
  • Stationary Molding Track
    Stationary Molding Track

Standard aluminum profiles

Popular sizes for standard aluminum awning profiles

Size Product Length
3/4" x 3/4" x .062" wall 6063-T52 Extruded Tubing - Sharp Corner 24'
3/4" x 3/4" x .125" wall 6063-T52 Extruded Tubing - Sharp Corner 24'
1" x 1" x .065" wall 6063-T6 Extruded Tubing - Round Corner 24'
1" x 1" x .090" wall 6063-T6 Extruded Tubing - Round Corner 24'
1" x 1" x .120" wall 6063-T6 Extruded Tubing - Round Corner 24'
1" x 1" x .125" wall 6063-T52 Extruded Tubing - Sharp Corner 24'
1" x 2" x .093" wall 6063-T6 Extruded Tubing - Round Corner 24'
1" x 2" x .125" wall 6063-T6 Extruded Tubing - Round Corner 24'
1" x 2" x .125" wall 6063-T52 Extruded Tubing - Sharp Corner 24'
1" x 4" x .125" wall 6063-T5 Extruded Tubing - Sharp Corner 12' & 24'
1-5/8"x 1-5/8" .100 wall 6063-T52 Extruded Tubing - Sharp Corner 24'
1-1/2" x 1-1/2" x .125" wall 6063-T52 Extruded Tubing - Sharp Corner 24"
1-1/2" x 1-1/2" x .125" wall 6063-T52 Extruded Tubing - Round Corner 24"
2" x 2" x .125" wall 6063-T6 Extruded Tubing - Round Corner 24"
2" x 2" x .125" wall 6063-T52 Extruded Tubing - Sharp Corner 21' & 24'
2" x 4" x .120" wall 6061-T6 Extruded Tubing - Round Corner 24' 8"
2" x 4" x .120" wall 6063-T52 Extruded Tubing - Sharp Corner 24'
3" x 3" x .125" wall 6063-T52 Extruded Tubing - Sharp Corner 24'
4" x 4" x .125" wall 6063-T52 Extruded Tubing - Sharp Corner 24'
1-1/2"OD x .085" wall 6063-T52 Extruded Tubing 20'
2"OD x .125" wall 6061-T6511 Extruded Tubing 24'
3"OD x .125" wall 6061-T6511 Extruded Tubing 24'
3/4" Schedule 40 6063-T5 Extruded Pipe 20'
1" Schedule 40 6063-T6 Extruded Pipe 20'
1-1/4" Schedule 40 6061-T6 Extruded Pipe 20'
1-1/2" Schedule 40 6063-T5 Extruded Pipe 20'
1-1/2" Schedule 80 6061-T6 Extruded Pipe 20'
2" Schedule 40 6061-T6 Extruded Pipe 20' 2"
2" Schedule 80 6061-T6 Extruded Pipe 20' 2"
2" Schedule 160 6061-T6 Extruded Pipe 20'
1/2" Diameter 6061-T6511 Extruded Bar 12' & 24'
5/8" Diameter 6061-T6511 Extruded Bar 12'
3/16" x 5" Flat 6061-T6511 Extruded Bar 12'
1/4" x 2" Flat 6061-T6511 Extruded Bar 12'
1/4" x 4" Flat 6061-T6511 Extruded Bar 12'

Advantages of aluminum alloy profiles for awnings

Lightweight: Aluminum alloy is much lighter than steel, making installation, transport, and adjustments easier while reducing the load on building structures.

High Strength: Despite being lightweight, aluminum alloy is sturdy enough to withstand the forces of an awning in the wind, ensuring overall stability.

Corrosion Resistance: Aluminum doesn't rust easily, and with proper treatment, it can resist moisture, rain, and UV exposure, making it ideal for outdoor use.

Easy to Process: Aluminum alloy can be fabricated into various shapes to meet different design needs. Whether it's simple straight frames or complex curved structures, aluminum can handle it with ease.

Aesthetically Pleasing: Aluminum alloy offers a range of colors and surface treatments, providing more aesthetic choices, making awnings more visually appealing.

Recyclable and Environmentally Friendly: Aluminum is a recyclable material, and using aluminum alloy helps reduce environmental pollution, aligning with eco-friendly principles.

Heat and Weather Resistance: Aluminum alloy maintains stability under various climates and temperatures, without significant impact from thermal expansion and contraction, making it suitable for all weather conditions.

Application cases

1 aluminum profiles for awnings
2 aluminum profiles for awnings
3 aluminum profiles for awnings


Why choose Mastar-Metal as your aluminum supplier?

  • We provide various quality inspection reports, ensuring product quality and giving you peace of mind.
  • Regular customers can enjoy a discount plan, making pricing more competitive.
  • We offer a wide variety of stock products with different sizes, with cutting services for the same dimensions, allowing for fast delivery.
  • We have a large collection of common aluminum profile molds, helping you save on tooling costs.
  • Custom shapes, sizes, and colors are supported to meet any decorative and aesthetic needs.
  • Excellent customer service, offering professional solutions for pre-sale consultations, technical support, and after-sales service to meet customer needs.
